Split Core DC Current Transducers

CR5210S DC Current Sensing Transducers are designed to provide a DC signal which is proportional to a DC sensed current. These devices are designed for direct current only, tartgeting them towards general and daily applications. The ranges 2 to 10 Amp utilize an advanced Magnetic Modulator technology and the ranges 20 amps and above utilize Hall Effect technology. The CR5210S has a +/- 5VDC that is Bi-Directional, ideal for battery charging applications.

CR5210S Split Core DC Current Transducers Features
• +/- 5 Vdc output
• 24 Vdc powered
• Use with external current transformers
• Highest precision available
• Connection diagram printed on case

CR5210S Split Core DC Current Transducers Specifications
• Basic Accuracy: 1.0%
• Thermal Drift: 500 PPM/°C
• Operating Temperature: 0°C to +60°C
• Installation Category: CAT II
• Polution Degree: 2
• Insulation Voltage: 2500 Vdc
• Altitude: 2000 meter max.
• Frequency Range: DC Only
• MTBF: Greater than 100 K hours
• Cleaning: Water-dampened cloth
• Supply Voltage: 24 Vdc ±10%
• Output Load: 2K Ω or Greater
• Response Time: 250 ms max. 0-90% FS
• Relative Humidity: 80% for temperatures up to 31°C and decreasing linearly to 50% at 40°C

CR5210S Split Core DC Current Transducers Applications
• Battery chargers and systems.
• DC Motor Drives
• Power Supply Management
• Mobile Applications

CR5210S Split Core DC Current Transducers PART NUMBERS
