Photosynthetically Active Radiation (PAR) Sensor
-
Price
Price on request ≥1piece
-
Model Number
ML-020P -
Data Sheet
-
Package
Original packaging -
Specs
ML-020P -
Quantity
- +Send Inquiry
Find Similar Products
-
Advanced Performance Photoelectric Sensor
Model Number：H60 Series
MOQ：1
-
Compact Photoelectric Sensor
Model Number：RP18 Series
MOQ：1
-
Cylindrical Photoelectric Sensor
Model Number：M12 Series
MOQ：1
-
Cylindrical Photoelectric Sensor
Model Number：M18 Series
MOQ：1
-
Universal Mount Photoelectric Sensor
Model Number：MP Series
MOQ：1
-
Miniature Photoelectric Sensor
Model Number：RP32 Series
MOQ：1
Product Description
ML-020P PAR Sensor Description
The compact ML-020P PAR sensor or Quantum sensor has a special opical filter to mimic the spectral response function of typical plant leaves. The PAR sensor is most common to be used in horticulture or agriculture aplications. The photon active range between 400 - 700 nm represents the Photosynthetically Active Radiation (PAR) known as Photosynthetic Photon Flux (PPF) or Photosynthetic Photon Flux Density (PPFD) in μmol/m/s (micromoles of photons per meters squared per second).
The low output Voltage of the sensor can be easily converted to a 4-20mA current or higher Voltage using the MS-4..20mA converter. The mV/mA converter can be pre-programmed and optimized within the operating range compatible with common measurement equipment.
ML-020P PAR Sensor Features
• Fast Response Time (10ms)
• Horticulture / Agriculture Purpose
• Compact Design
• PAR Response Curve
• Glass Dome Plus Diffusor Optics
• Low Temperature Dependency
ML-020P PAR Sensor Specifications
The compact ML-020P PAR sensor or Quantum sensor has a special opical filter to mimic the spectral response function of typical plant leaves. The PAR sensor is most common to be used in horticulture or agriculture aplications. The photon active range between 400 - 700 nm represents the Photosynthetically Active Radiation (PAR) known as Photosynthetic Photon Flux (PPF) or Photosynthetic Photon Flux Density (PPFD) in μmol/m/s (micromoles of photons per meters squared per second).
The low output Voltage of the sensor can be easily converted to a 4-20mA current or higher Voltage using the MS-4..20mA converter. The mV/mA converter can be pre-programmed and optimized within the operating range compatible with common measurement equipment.
ML-020P PAR Sensor Features
• Fast Response Time (10ms)
• Horticulture / Agriculture Purpose
• Compact Design
• PAR Response Curve
• Glass Dome Plus Diffusor Optics
• Low Temperature Dependency
ML-020P PAR Sensor Specifications
|
Specifications (Typical) |
ML-020 PAR |
|
Measurement Range |
0~3000 μmol•s-1•m-2 |
|
Output (Approx.) |
0~10,000μV (0~10mV) |
|
Internal Impedance |
160 Ω |
|
Operating temperature range |
-10 to +50°C |
|
Temp. response (-10 ~ +50°C) |
1.1 % |
|
Size |
Sensor Only: φ22 x 33mm With Mounting Plate: φ80 x 51mm |
|
Weight Sensor Only |
65g |
|
With Mounting Plate |
475g |
|
Cable length |
5 m |
|
*Mounting Plate |
Optional |
