CO Gas Alarm for CO Detection

CO Gas Leak Alarm for CO Detection

Applications:

For detecting CO leakage concentration in the air at home.

Features:

MCU controlreliable and low error;

On-spot audible and visual alarming;

Relay output--Activating the linkage device.

Obvious visible alarming indication, Seeing is Believing!

Specifications:

Detecting gas: CO

Working voltage: AC220V, AC110V, DC12V or DC24V

Consumption:<=1W

Response time: <=30s Resume automatically

Alarm level :100ppm

Working condition Tem.: 0'C~55'C Humidity: <95%RH

Alarm method: Audio and video alarm

Buzzer level: >=70dB

Dimension and weight: LxWxH, mm: 125 x 84 x 42, 290g

Output: Gas shut off valve output or relay output

Terminal connection: Easy to connect all the wires
