AC/DC Hall Effect Current Transducer
-
Price
Price on request ≥1piece
-
Model Number
CR5411S -
Data Sheet
-
Package
Original packaging -
Specs
CR5411S -
Quantity
- +Send Inquiry
Find Similar Products
-
Three-phase Open Loop Mode Hall Effect Current Sensor
Model Number：TKC-TG3
MOQ：1
-
High Precision Closed Loop Mode Hall Effect Current Sensor
Model Number：TBC-LTHB
MOQ：1
-
DC Leakage Current Sensor
Model Number：TDC-EB
MOQ：1
-
Hall Effect Voltage Sensor
Model Number：TBV-LV
MOQ：1
-
Hall Effect Voltage Transmitter
Model Number：TBV-AS12/24 Series
MOQ：1
-
RMS Dismountable Hall Effect Current Transmitter
Model Number：TKC-KDRA Series
MOQ：1
Product Description
CR5411S AC/DC Hall Effect Current Transducers are designed to provide a bipolar output that proportionally reflects the input bipolar current. These devices are specifically targeted to be used in applications where multi-mode current sensing is required. Ideal for closed loop applications.
CR5411S AC/DC Hall Effect Current Transducer Features
• +/-10 Vdc or +/-10 Vac outputs
• 24 Vdc powered
• Use with external current transformers
• Highest precision available
• Connection diagram printed on case
CR5411S AC/DC Hall Effect Current Transducer Specifications
• Basic Accuracy: 1.0%
• Calibration: True RMS Sensing, Average RMS, DC
• Thermal Drift: 500 PPM/°C
• Operating Temperature: 0°C to +60°C
• Installation Category: CAT II
• Polution Degree: 2
• Insulation Voltage: 2500 Vdc
• Altitude: 2000 meter max.
• Frequency Range: DC, DC to 4KHZ, 20 Hz - 5 KHz
• MTBF: Greater than 100 K hours
• Cleaning: Water-dampened cloth
• Supply Voltage: 24 Vdc ±10%
• Output Load: 2K Ohms or Greater
• Response Time: 0.25 ms max
• Relative Humidity: 80% for temperatures up to 31°C and decreasing linearly to 50% at 40°C
CR5411S AC/DC Hall Effect Current Transducer Applications
• Multi-mode ground paths carrying both AC and DC signals
• Feed back loop building block
• Inverter and multi-frequency drives
CR5411S AC/DC Hall Effect Current Transducer PART NUMBERS
