AC Current Transformer to DC Current (4-20 mA - Loop Powered)

Product Information

Power Supply:
Accuracy Class:
Max Error:
Temperature Coefficient:
EMI Error:
Response Time:

Protection Degree:
Operating Temperature:
Humidity:
Weight:
Dimensions:
Enclosure:
Configuration:
Mounting:
Standards:

5 to 28 V
0.2 %
0.2% o.m + 0.1% o.f.s.
< 150 ppm/K
< 50 μA
100 ms (without filter)
2.5 s (with filter)
IP 20
-20 to +65 °C
10-90% (non condensing)
47 g
38 x 40 x 20 mm
PBT, Black
DIP Switches (Range, Filter)
DIN Rail, Guide
CE, EN 61000-6-4, EN 64000-6-2
EN 61010-1, EN 60742

Input

Connection:
Hole Diameter:
Range:
Maximum Rating:
Self Consumption:
Isolation:

Passing - Through Hole
12.5 mm, 1/2"
Monopolar: 0-5, 0-10, 0-15, 0-20, 0-25, 0-30, 0-35, 0-40 A
< 800 A
< 50 mW
Over voltage measurement class: CAT III, 300 V towards earth, with an insulated wire.

Output

Type:
Terminals:
Other Protections:

Passive Current Loop 4-20 mA
Faston Terminals (60.3 x 0.8 mm)
Polarity reversal
Loop current limiting on hardware fault
Over temperature
