15x15 Indoor Air Quality Sensor 100 ppm P Package 110-801
-
Price
Price on request ≥1piece
-
Model Number
IAQ_100 P -
Data Sheet
-
Package
Original packaging -
Specs
IAQ_100 P -
Quantity
- +Send Inquiry
Find Similar Products
-
Air quality sensor VOC sensor
Model Number：TGS2600
MOQ：1
-
VOC Air quality sensor Formaldehyde sensor
Model Number：TGS2602
MOQ：1
-
for the detection of Air Contaminants
Model Number：TGS 8100
MOQ：1
-
Evaluation Module for TGS8100
Model Number：EM8100
MOQ：1
-
Ozone Sensor + Nitrogen Dioxide Sensor (O3 Sensor + NO2 Sensor)
Model Number：OX-B431
MOQ：1
-
Ozone + Nitrogen Dioxide Sensor (O3 + NO2 Sensor) 4-Electrode
Model Number：OX-A431
MOQ：1
Product Description
15x15 Indoor Air Quality Sensor 100 ppm P Package 110-801
IAQ_100 is a Screen Printed ElectroChemical sensor component specifically designed for the broad detection of gases associated with poor air quality: sulfides, alcohols, ammonia, odorous gases, and Carbon Monoxide.
IAQ_100 P Indoor Air Quality Sensor Benefits
• Zero Power Sensor
Sensor Circuit - < 10 uW max
• Cold operation - No Heating required
• Rugged Design - Not poisoned by sulfides, chlorides, NH3
• Stable Response - Not affected by humidity, CO2, N2, Ar, most saturated hydrocarbons, hexane
• Small Size& Low Profile - 20x20x3 mm
• Sensitive - In the ppm range
• Easy to Use - Linear Response
• Long Life - 10 years expected life
• Fast Response - < 20 seconds
• ROHS Compliant
IAQ_100 P Indoor Air Quality Sensor Applications
• Bad Air Quality Detection
• Indoor Air Monitor
• Air Purifier Controls
• Weather Stations
• Internet of Things
• Smart Homes
• Early Fire Detection
• Leak Detection
• HVAC Ventilation Control
IAQ_100 P Indoor Air Quality Sensor Specifications
Measurement Range
0 to 100 ppm (calibrated as CO equivalents)
Response Time to 90%
< 20 seconds typical
Sensitivity
12 +/- 3 nA/ppm (CO equivalents)
Expected Operating Life
> 5 years (10 years @ 23+/-3°C; 40+/-10% RH)
Operating Temperature Range
-10 to 40°C (0 to 40°C continuous)
Operating Humidity - non-condensing
0 to 100% RH (15 to 95% continuous)
Power Consumption
< 50 uW circuit & ambient gas dependent
Zero Drift (Over Temperature Range)
+/- 2 ppm (CO equivalents)
Lower Detection Limit
0.1 ppm CO (depends on the gas & electronics)
IAQ_100 P Indoor Air Quality Sensor Cross Sensitivity
This sensor exhibits sensitivity to a wide range of gases. The following table lists the relative response of common gases.
|
Gas |
ppm |
Typical Response (as ppm CO) |
|
Carbon Monoxide |
100 |
100 |
|
Hydrogen Sulfide |
100 |
370 |
|
Ozone |
100 |
-70 |
|
Nitrogen Dioxide |
100 |
-50 |
|
Sulfur Dioxide |
100 |
70 |
|
Ethanol |
100 |
140 |
|
Nitric Oxide (NO) |
100 |
80 |
|
Chlorine |
100 |
-50 |
|
n-Heptane |
100 |
0 |
|
Ammonia |
100 |
1 |
|
Methane |
100 |
0 |
|
Saturated Hydrocarbons |
100 |
0 |
